Technical details:
- Vertical mounting only
- Soft close damping system on the last 55 mm before the closed position
- High-gloss galvanized (chromated surface)
- Material: Cold-formed steel
- Installation length 550 mm
- Extension length 550 mm
- Load capacity for side mounting 80 kg / pair
- Easy removal of the drawer thanks to quick-release mechanism
- Hole pattern 32 mm
- Weight: 2.33 kg
Areas of application:
- Furniture construction
- Mechanical engineering
- Motorhome & caravan construction
- Special vehicle construction
- Warehouse equipment construction
- etc.
| Item weight: |
2,33 kg
|
| tab7 content: |
Other available lengths:
|
| Manufacturer information: |
Multislides GmbH
Robin Stoof
Sachsstrasse 16
50259 Pulheim-Brauweiler
Phone: +49 (0) 2234 - 68 83 611
Telefax: +49 (0) 2234 - 68 83 612
www.teleskopschienen24.de
info@teleskopschienen24.de
|
